Process
Quality Assurance / Process
American Standard Representative Process
Product
Products |
Symbol
Abbreviated Symbols |
Process
Process |
Description
Description |
|---|---|---|---|
CHQ WIRE
cold pier wire |
HD | PC-D |
PC: Pickling and phosphating LA: low temperature annealing A: Annealing SA: spheroidizing annealing RA: regular annealing D: Pull HD: straight pumping AIP: process annealing SAPP: Sphidiing Annealing & Pickling & Phosphating SAF: Sphidiing Annealing to Finished Dimensions SAIP: process spheroidizing annealing PASAF: Pre-annealed SAF PASAIP: Pre-annealed SAIP |
| RA | PC-RA | ||
| SA | PC-SA | ||
| RAIP | PC-RA-PC-D | ||
| (S)AIP | PC-SA-PC-D | ||
| SAF | PC-D-SA-PC | ||
| SAIP | PC-D-SA-PC-D | ||
| PASAF | PC-LA-PC-D-SA-PC | ||
| PASAIP | PC-LA-PC-D-SA-PC-D | ||
| PSASAIP | PC-D-SA-PC-D-SA-PC-D |
European standard representative process
Product
Products |
Types
Process Type
DIN 1654/10.89 |
Types
Process Type
EN 10263/02.02 |
Description
Description |
|---|---|---|---|
CHQ WIRE
cold pier wire |
K | +U+C |
cold drawn |
| K+GKZ | +U+C+AC |
cold-pick spheroidizing annealing |
|
| GKZ+K | +AC+C |
spheroidizing annealing secondary gentle drawing |
|
| K+GKZ+K | +U+C+AC+LC |
cold drawing spheroidizing annealing secondary light drawing |
|
| GKZ+K+GKZ | +AC+C+AC |
spheroidizing annealing cold drawing spheroidizing annealing |
|
| GKZ+K+GKZ+K | +AC+C+AC+LC |
spheroidizing annealing cold drawing spheroidizing annealing secondary light drawing |
